    SCHAAL SEP 80 SZV 302 Ref. 14126

    Automatic Punching Press Machine • 2001 • ID: 14126

    Frame and guidance on this unit are built for repeatability: a rigid double-column O-frame in vibration-damping cast iron, with the ram carried in 6-point play-free roller guides. Power is transmitted by a flywheel drive with pneumatic clutch/brake combination. Year of manufacture is 2001. Control and protection - Unidor electronic control system giving repeatable stroke accuracy and fast setup; integrated tool safety device protecting dies from damage caused by misfeeds or incorrect part positioning, which reduces downtime and tooling costs. Key data - pressing force 800 kN (80 tons); 60 – 320 min⁻¹; ram stroke adjustable 8 – 80 mm; ram adjustment 80 mm; ram surface 700 × 500 mm; clamping plate 830 × 700 mm at 80 mm thickness; table opening 500 × 200 mm; strip feed clearance 120 ± 40 mm; drive power 21.5 kW; weight 8,000 kg; footprint 1,500 × 2,000 mm with a height of 2,885 mm. Automated strip feeding is by the gripper feeding device SZV 302, for strip 10 – 270 mm wide and 0 – 4 mm thick. Schaal SEP 80, ref. no. 14126.

    This machine has been sold. If you are interested in a machine of this type, please contact us.

    Call Us

    Technical Specifications

    Pressing force800 kN (80 tons)
    Strokes per minute60 – 320 min⁻¹
    Ram stroke (adjustable)8 – 80 mm
    Ram adjustment80 mm
    Ram surface700 × 500 mm
    Table size (clamping plate)830 × 700 mm
    Clamping plate thickness80 mm
    Table opening500 × 200 mm
    Strip feed clearance120 ± 40 mm
    Feed unitSchaal SZV 3
    Strip width10 - 270 mm
    Thickness0 – 4 mm
    Drive power21.5 kW
    Weight8,000 kg
    Footprint1,500 × 2,000 mm, height: 2,885 mm
